A
B
C
AB
Figure 9-29
Removing the XSCF mount (for the SPARC M10-4 with a FRAME-B
CPU memory unit)
-
For the SPARC M10-4S with a FRAME-B CPU memory unit
Pull the XSCF mount upward (A in the figure) to remove it (B in the figure).
Figure 9-30
Removing the XSCF mount (for the SPARC
M10-4S with a FRAME-B
CPU memory unit)
7.
Remove the screw fixing the CPU memory unit board.
Fujitsu M10-4/Fujitsu M10-4S/SPARC M10-4/SPARC M10-4S Service Manual
･
November 2014212
