B
A
-
For
the
SPARC
M10-4/M10-4S
with
a
FRAME-A
CPU
memory
unit
Remove
the
one
black
screw
(A
in
the
figure)
securing
the
center
part
of
the
radiator
on
the
front
and
the
four
screws
securing
the
CPU
memory
unit
board
(B
in
the
figure).
Figure
9-31
　　
Screws
on
the
CPU
memory
unit
board
(for
the
SPARC
M10-4/M10-
4S
with
a
FRAME-A
CPU
memory
unit)
-
For
the
SPARC
M10-4/M10-4S
with
a
FRAME-B
CPU
memory
unit
Remove
the
one
black
screw
(A
in
the
figure)
securing
the
center
part
of
the
radiator
on
the
front
and
the
six
screws
securing
the
CPU
memory
unit
board
(B
in
the
figure).
Chapter
9
　
Maintaining
the
CPU
Memory
Unit/Memory 213
