Figure 28: Removing the PSU
▶
Remove the PSU and install the dummy cover carefully.
Note for PSU1:
Remove the PSU1 carefully while lifting PSU1 and bringing PSU1 to
the right, in order to avoid interference.
▶
Mount the complete assembly (CMA stopper, the crossbar and the CMA)
again into the rail.
Preliminary steps
▶
Only when replacing a PSU in a non-redundant configuration: "Shutting
down the server" on page
45.
Power supply unit (PSU)
RX2520 M5 Upgrade and Maintenance Manual 109
