Fujitsu PRIMERGY RX2520 M5 Upgrade And Maintenance Manual

14.3 Removing the serial interface 383
14.4 Replacing the serial interface 385
15 System board and components 387
15.1 Safety notes 387
15.2 Basic information 387
15.3 CMOS battery 388
15.3.1 Replacing the CMOS battery 388
15.4 Trusted Platform Module (TPM) 390
15.4.1 TPM kit 390
15.4.2 Installing the TPM 391
15.4.3 Removing the TPM 394
15.4.4 Replacing the TPM 399
15.5 iRMC microSD card 401
15.5.1 Note for embedded Lifecycle Management (eLCM) 401
15.5.2 Installing the iRMC microSD card 401
15.5.3 Removing the iRMC microSD card 403
15.5.4 Replacing the iRMC microSD card 404
15.6 M.2 SSD 405
15.6.1 Slots and bolts for M.2 SSDs 405
15.6.2 Installing an M.2 SSD 406
15.6.3 Removing an M.2 SSD 410
15.6.4 Replacing an M.2 SSD 411
15.7 Dual microSD 64GB Enterprise 413
15.7.1 Installing the Dual microSD 64GB Enterprise 413
15.7.2 Removing the Dual microSD 64GB Enterprise 417
15.7.3 Replacing the Dual microSD 64GB Enterprise 419
15.7.4 Replacing the microSD card 421
15.8 System board 423
15.8.1 Replacing the system board 423
Content
RX2520 M5 Upgrade and Maintenance Manual

Fujitsu PRIMERGY RX2520 M5 Specifications

General

Tcase	72 °C
Scalability	4S
Processor cache	16.5 MB
Processor cores	4
Processor model	5222
System bus rate	- GT/s
Processor socket	LGA 3647 (Socket P)
Processor threads	8
Processor codename	Cascade Lake
Execute Disable Bit	Yes
Motherboard chipset	Intel® C624
Processor frequency	3.8 GHz
Processor cache type	L3
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	76.0 x 56.5 mm
Processor boost frequency	3.9 GHz
Processor operating modes	64-bit
Embedded options available	No
Supported instruction sets	AVX-512
Thermal Design Power (TDP)	105 W
Number of processors installed	1
Maximum number of SMP processors	2
Maximum number of PCI Express lanes	48
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2933 MHz
Maximum internal memory supported by processor	1024 GB
HDD size	- \
RAID levels	0, 1
HDD interface	-
Supported HDD sizes	2.5 \
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Chassis type	Rack (2U)
Trusted Platform Module (TPM) version	2.0
Compatible operating systems	Microsoft Hyper-V Server 2016 Microsoft Windows Server 2016 Datacenter Microsoft Windows Server 2016 Standard Microsoft Windows Server 2016 Essentials Microsoft Windows Storage Server 2016 Standard Microsoft Hyper-V Server 2012 R2 Microsoft Windows Server 2012 R2 Datacenter Microsoft Windows Server 2012 R2 Standard Microsoft Windows Server 2012 R2 Essentials Microsoft Windows Storage Server 2012 R2 Standard VMware vSphere 6.5 VMware vSphere 6.0 SUSE Linux Enterprise Server 12 Red Hat Enterprise Linux 7 Red Hat Enterprise Linux 6 Univention Corporate Server 4
Memory slots	12
Internal memory	32 GB
Maximum internal memory	768 GB
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
Power supply	800 W
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 85 %
Certification	CB, RoHS, WEEE, GS, CE, CSAc/us, FCC Class A, ICES-003/NMB-003 Class A, VCCI:V3 Class A + JIS 61000-3-2, EAC, KC, CCC, RCM, BSMI
PCI Express slots version	3.0
PCI Express x16 (Gen 3.x) slots	3
On-board graphics card model	Not available
Processor ARK ID	192445

Weight and Dimensions

Depth	770 mm
Width	482.4 mm
Height	86.6 mm
Weight	25000 g
