Figure 72: Removing the installed SAS expander board (B)
▶
Remove the installed SAS expander board.
Figure 73: Disconnecting the connector card
▶
Disconnect the connector card with the SAS expander board.
Hard disk drive (HDD) / solid state disk (SSD)
RX2520 M5 Upgrade and Maintenance Manual 159
