Fujitsu PRIMERGY RX2520 M5

A
B
Figure 162: Installing the CPU frame on the heat sink (A)
▶
Position the CPU frame on the heat sink. Ensure that the triangle marks on
heat sink (A) and on CPU frame (B) are on the same edge.
Processor (CPU)
278 Upgrade and Maintenance Manual RX2520 M5
