Turn the heat sink upside down and check if all four blue washers are in
place, see
Figure 158.
Ensure that no screw falls out.
▶
Carefully align the heat sink with the CPU socket.
Take care of the pins. There is only one position which fits.
▶
Fasten the four captive screws in the sequence printed on the heat sink (1 to
4), by proceeding as follows:
T
orque: 1.4 Nm (not used in Japan)
▶
First, fasten the captive screws 1 and 2 completely
.
▶
Fasten the captive screws 3 and 4 completely.
Upgrading the main memory
▶
Select an adequate memory configuration for "2 CPUs populated", see
"Basic information" on page 258.
▶
Install memory modules, see "Installing a memory module" on page 263.
Installing an additional fan module
▶
If applicable, install an additional fan module in bay 3.
▶
Remove the fan cage foam from bay 3.
▶
Install the additional fan module, see "Installing the new fan module" on
page 213.
Concluding steps
▶
"Installing the air duct" on page 59.
▶
"Reassembling" on page 51.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 57.
Processor (CPU)
RX2520 M5 Upgrade and Maintenance Manual 281
