Fujitsu PRIMERGY RX2520 M5 Upgrade And Maintenance Manual

4.5.4 Sliding the server into the rack 55
4.6 Connecting the power cord 56
4.6.1 Connecting the power cord (AC PSU) 56
4.7 Switching on the server 57
4.8 Handling the air duct 58
4.8.1 Removing the air duct 58
4.8.2 Installing the air duct 59
4.9 Handling the fan holder 60
4.9.1 Removing the fan holder 60
4.9.2 Installing the fan holder 61
4.10 Handling the crossbar 62
4.10.1 Removing the crossbar 62
4.10.2 Installing the crossbar 63
5 Basic software procedures 65
5.1 Validation 65
5.2 Starting the maintenance task 65
5.2.1 Suspending BitLocker functionality 65
5.2.2 Disabling the boot watchdog 66
5.2.3 Removing backup and optical disk media 68
5.2.4 Verifying and configuring the backup software solution 68
5.2.5 Switching on the ID indicator 68
5.3 Completing the maintenance task 69
5.3.1 Updating or recovering the BIOS and iRMC S5 69
5.3.2 Verifying system information backup or restore 72
5.3.3 Updating expansion card firmware 73
5.3.4 Enabling Option ROM scan 74
5.3.5 Reconfiguring the backup software solution 75
5.3.6 Resetting the boot retry counter 76
5.3.7 Resetting the error status after replacing memory modules or
CPUs 78
5.3.7.1 Resetting the error status after replacing memory modules 78
Content
RX2520 M5 Upgrade and Maintenance Manual

Fujitsu PRIMERGY RX2520 M5 Specifications

General

Tcase	72 °C
Scalability	4S
Processor cache	16.5 MB
Processor cores	4
Processor model	5222
System bus rate	- GT/s
Processor socket	LGA 3647 (Socket P)
Processor threads	8
Processor codename	Cascade Lake
Execute Disable Bit	Yes
Motherboard chipset	Intel® C624
Processor frequency	3.8 GHz
Processor cache type	L3
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	76.0 x 56.5 mm
Processor boost frequency	3.9 GHz
Processor operating modes	64-bit
Embedded options available	No
Supported instruction sets	AVX-512
Thermal Design Power (TDP)	105 W
Number of processors installed	1
Maximum number of SMP processors	2
Maximum number of PCI Express lanes	48
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2933 MHz
Maximum internal memory supported by processor	1024 GB
HDD size	- \
RAID levels	0, 1
HDD interface	-
Supported HDD sizes	2.5 \
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Chassis type	Rack (2U)
Trusted Platform Module (TPM) version	2.0
Compatible operating systems	Microsoft Hyper-V Server 2016 Microsoft Windows Server 2016 Datacenter Microsoft Windows Server 2016 Standard Microsoft Windows Server 2016 Essentials Microsoft Windows Storage Server 2016 Standard Microsoft Hyper-V Server 2012 R2 Microsoft Windows Server 2012 R2 Datacenter Microsoft Windows Server 2012 R2 Standard Microsoft Windows Server 2012 R2 Essentials Microsoft Windows Storage Server 2012 R2 Standard VMware vSphere 6.5 VMware vSphere 6.0 SUSE Linux Enterprise Server 12 Red Hat Enterprise Linux 7 Red Hat Enterprise Linux 6 Univention Corporate Server 4
Memory slots	12
Internal memory	32 GB
Maximum internal memory	768 GB
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
Power supply	800 W
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 85 %
Certification	CB, RoHS, WEEE, GS, CE, CSAc/us, FCC Class A, ICES-003/NMB-003 Class A, VCCI:V3 Class A + JIS 61000-3-2, EAC, KC, CCC, RCM, BSMI
PCI Express slots version	3.0
PCI Express x16 (Gen 3.x) slots	3
On-board graphics card model	Not available
Processor ARK ID	192445

Weight and Dimensions

Depth	770 mm
Width	482.4 mm
Height	86.6 mm
Weight	25000 g
