Fujitsu PRIMERGY RX2520 M5 Upgrade And Maintenance Manual

5.3.7.2 Resetting the error status after replacing CPUs 79
5.3.8 Enabling the boot watchdog 81
5.3.9 Enabling replaced components in the BIOS 82
5.3.10 Verifying the memory mode 83
5.3.11 Verifying the system time settings 84
5.3.12 Viewing and clearing the System Event Log (SEL) 85
5.3.13 Updating the NIC configuration file in a Linux and VMware
environment 87
5.3.14 Resuming BitLocker functionality 88
5.3.15 Performing a RAID array rebuild 89
5.3.16 Looking for MAC/WWN/GUID and SAS addresses 90
5.3.16.1 Basic information 90
5.3.16.2 Looking for the MAC address of a LAN controller 90
5.3.16.3 Looking for the WWN address of a fibre channel controller 92
5.3.16.4 Looking for the GUID address of an infiniband or Omni-Path
controller 92
5.3.16.5 Looking for SAS addresses of SAS controllers for external
devices 93
5.3.17 Using the Chassis ID Prom Tool 94
5.3.18 Configuring LAN teaming 96
5.3.19 Switching off the ID indicator 97
5.3.20 Performing a fan test 98
6 Power supply unit (PSU)
101
6.1 Safety notes 101
6.2 Basic information 101
6.3 Redundant power supply 103
6.3.1 Installing a hot-plug PSU 103
6.3.2 Removing a hot-plug PSU 106
6.3.3 Replacing a hot-plug PSU 111
6.4 Power distribution board 113
6.4.1 Installing the power distribution board 113
6.4.2 Removing the power distribution board 117
6.4.3 Replacing the power distribution board 120
Content
Upgrade and Maintenance Manual RX2520 M5

Fujitsu PRIMERGY RX2520 M5 Specifications

General

Tcase	72 °C
Scalability	4S
Processor cache	16.5 MB
Processor cores	4
Processor model	5222
System bus rate	- GT/s
Processor socket	LGA 3647 (Socket P)
Processor threads	8
Processor codename	Cascade Lake
Execute Disable Bit	Yes
Motherboard chipset	Intel® C624
Processor frequency	3.8 GHz
Processor cache type	L3
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	76.0 x 56.5 mm
Processor boost frequency	3.9 GHz
Processor operating modes	64-bit
Embedded options available	No
Supported instruction sets	AVX-512
Thermal Design Power (TDP)	105 W
Number of processors installed	1
Maximum number of SMP processors	2
Maximum number of PCI Express lanes	48
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2933 MHz
Maximum internal memory supported by processor	1024 GB
HDD size	- \
RAID levels	0, 1
HDD interface	-
Supported HDD sizes	2.5 \
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Chassis type	Rack (2U)
Trusted Platform Module (TPM) version	2.0
Compatible operating systems	Microsoft Hyper-V Server 2016 Microsoft Windows Server 2016 Datacenter Microsoft Windows Server 2016 Standard Microsoft Windows Server 2016 Essentials Microsoft Windows Storage Server 2016 Standard Microsoft Hyper-V Server 2012 R2 Microsoft Windows Server 2012 R2 Datacenter Microsoft Windows Server 2012 R2 Standard Microsoft Windows Server 2012 R2 Essentials Microsoft Windows Storage Server 2012 R2 Standard VMware vSphere 6.5 VMware vSphere 6.0 SUSE Linux Enterprise Server 12 Red Hat Enterprise Linux 7 Red Hat Enterprise Linux 6 Univention Corporate Server 4
Memory slots	12
Internal memory	32 GB
Maximum internal memory	768 GB
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
Power supply	800 W
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 85 %
Certification	CB, RoHS, WEEE, GS, CE, CSAc/us, FCC Class A, ICES-003/NMB-003 Class A, VCCI:V3 Class A + JIS 61000-3-2, EAC, KC, CCC, RCM, BSMI
PCI Express slots version	3.0
PCI Express x16 (Gen 3.x) slots	3
On-board graphics card model	Not available
Processor ARK ID	192445

Weight and Dimensions

Depth	770 mm
Width	482.4 mm
Height	86.6 mm
Weight	25000 g
