Chapter 8: Image Viewer
Definium 5000 X-Ray System 5197809-1EN Rev. 4 (13 February 2008) 8-25
Operator Manual © 2008 General Electric Company. All rights reserved.
5. Press [PRINT] to print the image.
[CANCEL] closes the Print Images screen without printing and returns you to the Image Viewer
screen.
Figure 8-22 Print Images screen
Table 8-8 Print Images field description
Field Description
Printer Lists all available printers configured for your system.
Orientation Selects vertical or horizontal orientation of the image on film or paper.
Available options are:
• Landscape
•Portrait
Print Mode Selects what size to print the image.
Available options are:
•True Size
• Fit to Film
• Reduce Size
• Orthopedic Magnification (if enabled)
Magnification If Reduce Size is selected as the Print Mode, allows you to enter the percent by
which the image will be reduced. The accepted range is between 40% and 90%.
If True Size or Fit to Film are selected as the Print Mode, the text box remains
disabled.
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
