Chapter 3: System Overview
Definium 5000 X-Ray System 5197809-1EN Rev. 4 (13 February 2008) 3-24
Operator Manual © 2008 General Electric Company. All rights reserved.
Image Pasting Patient Positioner
Image Pasting is a purchased option for the Definium 5000.The positioner is used to determine the
correct Center of Interest (COI) and to accurately re-construct images.
Refer to Appendix A:
Image Pasting for more information.
Figure 3-29 Image Pasting Patient Positioner
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
