Chapter 8: Image Viewer
Definium 5000 X-Ray System 5197809-1EN Rev. 4 (13 February 2008) 8-27
Operator Manual © 2008 General Electric Company. All rights reserved.
Orthopedic Magnification
Orthopedic Magnification is an option that allows you to introduce a fixed amount of magnification
percentage so that the image size will match previously calibrated orthopedic templates.
This section provides instruction on printing images with Orthopedic Magnification.
NOTE: The functions described in this section are only available if Orthopedic Magnification is enabled.
GE Service personnel enable Orthopedic Magnification and enter the Configurable Magnification
Factor (CMF) through the Services User Interface. The CMF is the amount of magnification applied
to all Orthopedic Magnification functions. Only GE Service personnel are able to change the CMF.
Only processed images will have Orthopedic Magnification applied. The raw images remain as acquired.
Send Images
If Auto Send is enabled, acquired images are automatically sent to a pre-determined location on exam
close. Refer to Chapter 10:
Set Preferences-Auto Send (Auto Push) (p. 10-22) for information on
configuring Auto Send.
Save Changes to Images
You have the option to save or discard the changes you have made to images when you close the Image
Viewer screen or end the exam.
1. If in a live exam, press [CLOSE] on the Acquisition screen.
2. If in review mode, press [CLOSE] on the Image Viewer screen.
A message appears: “Would you like to save the changes made to the images?”
3. Press [YES].
[NO] closes the Image Viewer screen without saving changes.
