Chapter 9: Image Management
Definium 5000 X-Ray System 5197809-1EN Rev. 4 (13 February 2008) 9-12
Operator Manual © 2008 General Electric Company. All rights reserved.
6. Confirm the exams to be copied. Uncheck any exams that you do not want saved to the CD.
7. Press [WRITE].
The CD begins copying. The light on the front of the computer flashes yellow as the data is being
written.
To see the status of the exams being copied, press [TRANSFER LOG] at the bottom of the Image
Management screen.
The Transfer Log screen appears.
Press [CLOSE] to close the screen and return to the Image Management screen.
When complete, the CD tray will open and close.
8. After the system finishes the CD, open the exams on the CD to ensure that the CD has the data
written to it. Refer to Load Images from a CD
(p. 9-6) for more information.
9. Remove the CD.
10. Label the CD and store in a safe place.
Delete Exams, Series, or Images
Exams, series, and images may be deleted from the local database from the Image Management screen.
Follow this process to delete exams, series, and images.
1. Select the Local source, if necessary.
NOTE: Items cannot be deleted from a CD or network locations.
2. Unlock exams, if necessary.
Refer to Lock Exams from Deletion
(p. 9-13) for more information.
3. Select the items to delete.
The items may be exams, series with an exam, or images within a series. Multiple items may be
selected and deleted at once.
4. Press [DELETE].
A message appears: “Are you sure that you would like to delete the selected items?”
5. Press [OK].
The message closes.
The items are deleted from the Image Management screen.
[CANCEL] closes the message and the items remain on the Image Management screen.
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
