Chapter 10: Set Preferences
Definium 5000 X-Ray System 5197809-1EN Rev. 4 (13 February 2008) 10-8
Operator Manual © 2008 General Electric Company. All rights reserved.
Add or Edit DICOM Printers
Adding and editing printers use very similar process and the same screens shown in Figure 10-6,
Figure 10-7, and Figure 10-8. Table 10-3, Table 10-4, and Table 10-5 describe the fields in detail.
1. If Editing an existing printer’s configuration, select the printer from the DICOM Printers list and press
[EDIT].
 If adding a new printer, press [ADD].
2. Complete requested information for all tabs (see Table 10-3, Table 10-4, and Table 10-5) and press
[SAVE] to add the printer or save the changes.
Figure 10-6 Add Printer screen – Printer Tab
Table 10-3 Add Printer screen– Printer Tab description
Function Description
DICOM Printer Label The name of the printer that appears in the DICOM Printers list and on the
print setup screens.
NOTE: DICOM printer labels cannot have spaces in the name. Use underscores
( _ ) to separate words.
Application Entry
Title
The DICOM application title.
Network Address The IP address of the printer.
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
