Appendix C: Technical Specifications
Definium 5000 X-Ray System 5197809-1EN Rev. 4 (13 February 2008) C-2
Operator Manual © 2008 General Electric Company. All rights reserved.
Factors
Duty Cycle
18 exposures per hour at maximum mAs, using the X-ray tube: Toshiba E7254FX.
Generator Accuracy
X-Ray Source Assembly Filtration
The x-ray source assembly is made up of the x-ray tube and the collimator. Together, they provide
permanent, non-removable filtration of 3.6mm aluminum equivalent @ 80 kVp.
Factors Generator SHF-635
Maximum Power kW 65 kW
Maximum mA 550 mA
Maximum kVp 150 kVp
Power Output
(@0.1 s)
650 mA @ 40-98 kVp
500 mA @ 99-128 kVp
400 mA @ 129-150 kVp
Tube Voltage Range X-Ray voltage range: 40kVp - 150kVp in 1 kVp steps
Allowable deviation: +/- (3% + 1kV)
Tube Current Range X-Ray tube current range: 10 - 650 mA (65kW)
Allowable deviation: +/- (4% + 1mA)
Accuracy of Exposure Amount
(mAs)
0.1 mAs - 520 mAs
Manual mode maximum mAs limited to 520 mAs
AEC mode maximum mAs limited to 512 mAs
Time of Exposure 1ms - 2000ms
Allowable deviation: +/- (2% + 0.1ms)
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
