Chapter 3: System Overview
Definium 5000 X-Ray System 5197809-1EN Rev. 4 (13 February 2008) 3-21
Operator Manual © 2008 General Electric Company. All rights reserved.
Options and Accessories
The following sections identify accessories for the Definium 5000 that may be purchased separately.
Copper Filtration
Copper filtration is a purchasable option. The switch for the copper filter is located on the right side of the
collimator and allows a selection of 0.0mm, 0.1mm, or 0.2mm of copper filtration.
CAUTION: If copper filtration is changed on the Acquisition screen, the operator must manually
change the filtration selection on the collimator before making the exposure.
Figure 3-25 Cu Filter switch on collimator - 0.1mm selected
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
