System Movement Controls
Controls to move and position the system are provided in four places: control panel, receptor handle,
CRIB, and a remote control (optional). Table 3-4 shows the symbols on the controls and describes their
function.
Figure 3-7 Control Panel, Receptor Handle, Remote Control, and CRIB
Control Panel
Receptor Handle Remote Control
CRIB
