H3C WA Series User Manual

312
Figure 326 Enable the wireless service
8. Optional: Enable 802.11n radio (By default, 802.11n radio is enabled.)
Select Radio > Radio from the navigation tree to enter the Radio page. Make sure 802.11n is
enabled.
Configuring the RADIUS server (iMCv3)
NOTE:
The following takes the iMC (iMC PLAT 3.20-R2602 and iMC UAM 3.60-E6102) as an example to
illustrate the basic configuration of the RADIUS server.
1. Add access device.
a. Select the Service tab in the iMC management platform.
b. Select Access Service > Access Device from the navigation tree.
c. Click Add.
d. On the page that appears, add expert for Shared Key, add ports 1812, and 1813 for
Authentication Port and Accounting Port respectively, select LAN Access Service for Service
Type, select H3C for Access Device Type, and select or manually add an access device with the
IP address 10.18.1.1, and click Apply.
