RDR—Receive Data Register H'FFDD SCI
Bit 76543210
Initial value 00000000
Read/Write RRRRRRRR
Receive data
ADDRn (H)—A/D Data Register n (High)
H'FFE0, H'FFE2, H'FFE4, H'FFE6 (n = A, B, C, D) A/D
Bit 76543210
AD
9 AD8 AD7 AD6 AD5 AD4 AD3 AD2
Initial value 00000000
Read/Write RRRRRRRR
Upper 8 bits of 10-bit A/D conversion result
ADDRn (L)—A/D Data Register n (Low)
H'FFE1, H'FFE3, H'FFE5, H'FFE7 (n = A, B, C, D) A/D
Bit 76543210
AD
1 AD0 ——————
Initial value 00000000
Read/Write RRRRRRRR
Lower 2 bits of 10-bit A/D conversion result
397
