Item Description
A hyphen (-) is displayed as RPM when the drive is SSD.
1
Drive Type-Code Type code of the drive of the parity group where the logical volume belongs
1
Drive Capacity Capacity of the drive of the parity group where the logical volume belongs.
1
PG Members List of the drive locations of the parity group where the logical volume belongs
1
Allocated Information about whether the host can access the logical volume.
For mainframe volumes and multi-platform volumes, "Y" is displayed unless the
volumes are in the reserved status.
SSID SSID of the logical volume
CVS Information about whether the logical volume is a customized volume
OCS Oracle checksum
Attribute The attribute of the logical volume
Provisioning Type Provisioning type of the logical volume
Pool Name
• For V-VOLs of Dynamic Provisioning, the name of the pool related to the logical
volume is displayed
1
• If the logical volume attribute is Pool, the name of the pool where the logical
volume belongs is displayed
• When neither of the above are displayed, the pool name is blank
Pool ID The ID of the pool indicated by "Pool Name" A hyphen (-) displays for volumes other
than pool-VOLs or V-VOLs
Current MPU The number of the MP unit that currently controls the logical volume
Setting MPU The number of the MP unit that you specified to control the logical volume
Command Device: Security Indicates whether Security is specified as the attribute for the command device. A
hyphen (-) displays when "Attribute" is not "CMDDEV".
Command Device:
User Authentication
Indicates whether User Authentication is specified as the attribute for the command
device. A hyphen (-) displays when "Attribute" is not "CMDDEV".
Command Device:
Device Group Definition
Indicates whether Device Group Definition is specified as the attribute for the
command device. A hyphen (-) displays when "Attribute" is not "CMDDEV".
Encryption Indicates whether the parity group to which the LDEV belongs is encrypted.
• For internal volumes: Enabled (encrypted) or Disabled (not encrypted)
• For external volumes: blank
T10 PI Indicates the T10 PI attribute set for the LDEV.
• Enabled
• Disabled
• Blank if the emulation type is not OPEN-V
ALUA Mode Indicates whether the ALUA mode is enabled:
• Enabled: ALUA mode is enabled.
• Disabled: ALUA mode is disabled.
Notes:
1. A hyphen (-) displays if the LDEV is an external volume.
Examples of storage configuration reports 287
System Administrator Guide for VSP Gx00 models and VSP Fx00 models
