Hitachi VSP G400 System Administration Guide

Item Content
• If the number starts with "E" (for example, E1-1), the parity group contains
external volumes.
• If the type of the LDEV is a Dynamic Provisioning or Thin Image virtual volume, a
hyphen is output.
Refer to "LdevInfo.csv" for information about the LDEV type.
LDEV#(V-VOL) LDEV number allocated to this CLPR.
• VSP G200: (00:00:00 to 00:07:ff)
• VSP G400, G600 or VSP F400, F600: (00:00:00 to 00:0f:ff)
• VSP G800 or VSP F800: (00:00:00 to 00:3f:ff)
The type of this LDEV is Dynamic Provisioning, Thin Image, or ALU.
LunInfo.csv
This CSV file contains information about LU path definitions. A record is
created for each host group. For more information about LU path definitions,
see the Provisioning Guide.
Table 43 LunInfo.csv file (Title: <<LUN Information>>)
Item
Description
Port Port name
Host Group Host group name
If "Package Type" is iSCSI, the iSCSI target alias is output.
Host Mode Host mode specified for this host group (hexadecimal)
Host Mode Option Host mode option set for this host group (0 to 127, hexadecimal)
If more than one option is specified, the options are separated by semicolons (;).
LUN# LUN number for this LU path definition (hexadecimal)
LDEV# LDEV number for this LU path definition
Command Device Information about whether the LDEV is a command device:
• On: Command Device
• On*: Remote Command Device
• Off: Others
Command Security Information about whether the command device is secured:
• On
• Off
CVS Information about whether the LDEV is a custom-sized volume:
• On: Customized volume
• Off: Other volumes
CHB Location Name of the CHB on which this port is installed
CHB-1A/1B/1C/1D or CHB-2A/2B/2C/2D if Package Type is NAS module.
Package Type CHB type for CHB Location:
• Fibre:
○ 8FC4 (CHB)
○ 16FC2 (CHB)
○ 32FC4R (CHB)
336 Examples of storage configuration reports
System Administrator Guide for VSP Gx00 models and VSP Fx00 models
