Item Description
Location Name of physical devices
CR# C# and R# to define physical devices
Output as "XX/YY"
PG Parity group of physical devices
Emulation Type Parity group of physical devices
Drive type Drive type of physical devices
• SAS
• SSD
RPM
Revolutions-per-minute (RPM) in the parity group
• 8000
• 15000
A hyphen (-) is displayed instead of the RPM when the drive type is an SSD.
Drive Type-Code Type code of the drive in the parity group.
Output example: SLR5B- M200SS;SFB5A-M200SS; (if multiple drive types are set)
Drive Size
Drive size (inches)
• 2.5
• 3.5
Drive Capacity Physical drive capacity (GB or TB)
Drive Version Firmware version of the drive
DKB1 Name of the DKB1 which controls the physical devices
DKB2 Name of the DKB2 which controls the physical devices
Serial Number#
Serial product number of the physical devices
• yy: year (last 2 digits)
• mm: month (2 digits)
• xxxxxxxx: product number of the physical devices
RAID Level RAID level of the physical devices
• RAID1(2D+2D)
• RAID5(7D+1P)
• RAID6(6D+2P)
• RAID6(14D+2P)
RAID Concatenation#0 Number indicating a parity group #0 connected to this parity group
Output example: 2-1, 3-1, 4-1
RAID Concatenation#1 Number indicating a parity group #1 connected to this parity group
Output example: 2-1, 3-1, 4-1
RAID Concatenation#2 Number indicating a parity group #2 connected to this parity group
Output example: 2-1, 3-1, 4-1
Resource Group Name Name of resource group to which the parity group of physical devices belong
Resource Group ID ID (0 to 1023 binary)
Encryption Enable or disable status of the parity group to which the physical devices belong
• Enabled: Encryption is enabled.
• Disabled: Encryption is disabled.
292 Examples of storage configuration reports
System Administrator Guide for VSP Gx00 models and VSP Fx00 models
