Table 55 PkInfo.csv file (Title: <<PK>>)
Item Content
CHB Location CHB name
CHB-1A/1B/1C/1D or CHB-2A/2B/2C/2D if "Package Type" is NAS module.
Port# Number of the port installed on the CHB (2-digit hexadecimal number)
Port Name of port installed on the CHB
Package Type CHB type indicated on the CHB Location
• Fibre: 8FC4 (CHB), 16FC2 (CHB), 32FC4R (CHB)
• iSCSI: 10iSCSI2o (CHB), 10iSCSI2c (CHB)
• NAS module: NAS module (CHB)
SFP Kind SFP (Small Form factor Pluggable) Kind
• Short Wave
• Long Wave
• Blank if "Package Type" is 10iSCSI2c (CHB) or NAS module (CHB).
SFP Status SFP Status:
• Normal
• Failed
• Not Fix
• Blank if "Package Type" is 10iSCSI2c (CHB) or NAS module (CHB).
Fabric One of the Fibre topology settings indicating the setting status of the Fabric switch:
• On
• Off
• Blank if "Package Type" is iSCSI or NAS module.
Connection One of the Fibre topology settings
• Point to Point
• FC-AL
• Blank if "Package Type" is iSCSI or NAS module.
Port Address Port address (00 to ff, 2-digit hexadecimal number)
Blank if "Package Type" is iSCSI or NAS module.
Resource Group ID (Port) Resource group ID of port (0 to 1023, decimal number)
Resource Group Name (Port) Resource group name of the port.
Port Internal WWN Port WWN
Blank if "Package Type" is iSCSI or NAS module.
T10 PI Mode Indicates whether the T10 PI mode can be applied to the port.
• Enabled
• Disabled
• Blank if "Package Type" is not 16FC2 (CHB) or 32FC4R (CHB).
SFP Data Transfer Rate Maximum transfer rate of SFP which the mounted package supports.
• 8G
• 10G
• 16G
• 32G
• Blank if the "Package Type" is 10iSCSI2c (CHB) or NAS module (CHB).
Examples of storage configuration reports 345
