Operation C250 ... C370
134 Translation of Original Operating Manual 156319-04
Air outlet nozzles
C270_067
9 9910 10
C250, C270
There are several air outlet nozzles (9, 10) in the
cab:
– Ventilation slots (9) in the cab trim for front
and side windows
– Adjustable nozzles (10) in front of the steering
column
1. Adjust the air flow to the desired direction by
using the air outlet nozzles (10)!
C370_016
9 99 910 1010
C350, C370
