Holder C270 - Engine technical data

Maintenance Data C250 ... C370
Translation of Original Operating Manual 156319-04 257
Engine technical data
Vehicle type C250, C350 C270, C370
Manufacturer Kubota
Model designation V2607-DI-EU3 V2607-DI-T-EU3
Design Vertical in-line
Mode of operation Four-stroke diesel
Cooling Liquid cooling
Injection method Direct injection
Number of cylinders 4
Cylinder bore 87 mm
Stroke 110 mm
Displacement 1615 cm
3
Compression ratio 19:1
Fuel consumption 220g/kwh at 1600 rpm 220g/kwh at 1600 rpm
Lubrication oil consumption Max. 0.5% of fuel consumption
Oil filter Kubota oil filter
Rated speed 2700 min
-1
Max. torque as per 97/68 EC 170 Nm at 1600 rpm 217 Nm at 1600 rpm
Power as per 97/68 EC at 3000 rpm 36.5 kW (50 HP) 48.5 kW (67 HP)
Firing order 1-3-4-2
