Holder C270 - Front PTO shaft drive*

Attachments C250 ... C370
Translation of Original Operating Manual 156319-04 185
Front PTO shaft drive*
C270_157
13
15
1a 1
C270_158
15
1a
1a
13
ADVICE
The PTO shaft switch (15) is indepen-
dent of the master switch for the hy-
draulics (13).
The PTO shaft rotates clockwise (view onto the end
of the shaft). The rotational speed is 1000 rpm at
an engine speed of 2500 rpm.
Switching on and off
1. Reduce engine speed.
2. Unlock the catch on the safety switch (15)
and press the switch downwards. The PTO
shaft drive is switched on.
3. Increase the engine speed to the desired PTO
shaft rotational speed (see multifunction dis-
play).
4. Press the safety switch upwards to switch off
the drive. PTO shaft drive is switched off.
* Optional equipment
