Accessibility (from above)
C270_055
If necessary, you can lift the frame with the tipping
system* or manually for the checks or the service.
Hydraulic tipping system*
1. Detach all attachments at the rear end and
move them out of the way.
2. Raise tilting system* (see Attachments "Tilt-
ing system, rear lift", page 180).
Body frame
1. Detach all attachments at the rear end and
move them out of the way.
2. Lift body frame manually. (see Attachments
"Manual body frame", page 182).
3. Secure body frame in the raised position.
CAUTION
Danger of accident
Working under the raised body frame
is permitted only with additional sup-
port put into place.
WARNING
Danger of burns from hot parts
Allow vehicle and engine to cool down
first
* Optional equipment
