Holder C270 - Attachments, Cargo bed tipping system

To Next Page

To Previous Page

Attachments C250 ... C370

Translation of Original Operating Manual 156319-04 157

Attachments, Cargo bed tipping system

C270_116

100 mm

ADVICE

The distance (1) between the air in-

take grating and the attached imple-

ment must be at least 100 mm.

ADVICE

Assure sufficiently large openings for

supply of air on the longitudinal beams

(2).
