Attachments C250 ... C370
Translation of Original Operating Manual 156319-04 163
Operating the joystick
ADVICE
The functions of the attachments that
are connected to the front lift or to the
hydraulic couplings at the front or the
rear are controlled with the joystick.
The couplings are colour-marked, i.e.,
an identical colour corresponds to an
identical assignment.
DANGER
Danger of accident
•
Because of the variety of attach-
ments and connection possibilities,
check functions by a test run be-
fore use
•
Carry out the test run at a secure
location
ADVICE
The joystick can be moved down (for-
ward) and up (backward), as well as to
the right and the left. Additional func-
tions can be activated by pressing var-
ious keys
