Holder C270 - Operating elements in the operating console

To Next Page

To Previous Page

Description C250 ... C370

Translation of Original Operating Manual 156319-04 57

Operating elements in the operating console

C270_018

1 Handle for adjusting the armrest

2 Switch for double acting or single acting

(front lift)

3 Selector switch, front lift inclination adjust-

ment

4 Operating console

5 Control wheel for adjusting the height of the

operating console
