Attachments C250 ... C370
Translation of Original Operating Manual 156319-04 143
Permissible gross weight
WARNING
Danger of accident
•
When attaching implements to the front and rear three-point linkages, never exceed the
permissible gross weight, the permissible axle loads or the tyre load capacity of the ve-
hicle
•
Always load the front axle of the vehicle with at least 20% of the vehicle's kerb weight.
1. Make sure that these requirements are satisfied before purchasing the implement.
2. Carry out the following calculations or weigh the vehicle-implement combination.
Determination of the gross weight, the axle loads and tyre load capacity, as well as the re-
quired minimum ballasting
You require the following data for the calculation:
T
L
[kg] Kerb weight of the vehicle
1)
T
V
[kg] Front axle load of the empty vehicle
1)
T
H
[kg] Rear axle load of the empty vehicle
1)
G
H
[kg] Total weight of rear attachment, rear ballast
2)
G
V
[kg] Total weight of front attachment, front ballast
2)
a [m] Distance between centre of gravity of front attachment, front ballast and centre of
front axle
2)3)
b [m] Wheelbase of the vehicle
1)3)
