Attachments C250 ... C370
Translation of Original Operating Manual 156319-04 181
ADVICE
Observe the position of the
changeover valve for "Lateral adjust-
ment of front lift" page 168.
Lifting, lowering
1. To lift the tilting system or rear lift, press key
(3) backwards. The tilting system or rear lift
is raised as long as the key is pressed.
2. To lower the tilting system or rear lift, press
key (3) forwards. The front lift is lowered as
long as the key is pressed.
3. The movement is stopped by releasing the
key.
Operating floating position
1. To activate, press key (3a). Lamp in key lights
up.
2. Deactivate the floating position by pressing
key (3). Light in key (3a) goes out.
WARNING
Danger of accident
The tilting system or the lifted imple-
ment lowers itself when the floating
position is switched on.
•
Never stand underneath attach-
ments or tipping systems
* Optional equipment
