Tip:
To add columns other than these to the current display, click the Show column
organizer icon to display the full list of available columns, and then select those
you would like included.
Column Description
Date &
Time
The time and date at which the event was received.
Location The tag name of the asset to which the point or device belongs.
Source
The point or device that caused the event.
If the point ID is too long to be fully displayed in the alarm summary, it is truncated.
To see the full name place the mouse pointer over the partial point ID to display the
full point ID.
Condition The event condition.
Action
The action, either operator or system generated.
ACK. Alarm acknowledged.
ACK PNT. All alarms on a point acknowledged at the same time. That is, the user
has selected an object on a schematic and pressed the Ack key. Each alarm that
was acknowledged is journaled, as is the summary ACK.PNT event. For example,
for a point with PVHI and PVHIHI alarms active, three events are journaled: ACK
for PVHI, ACK for PVHIHI, and the ACK PNT summary.
DISCARD. Alarm discarded due to alarm list overflow.
OK. Alarm returned to normal.
SHELVE. Alarm shelved.
UNSHELVE. Alarm unshelved.
ACTIVE. Suppression group activated.
INACTIVE. Suppression group deactivated.
SUPP. Alarm has been suppressed.
UNSUPP. Alarm has been unsuppressed.
Blank. No action has occurred.
For a list of Safety Manager actions, refer to the “SOE log entries reference” topic
in the Safety Manager Integration Guide.
Responding to events
Honeywell 2017 164
