Example SCADA point faceplates
Status point Analog point Accumulator point
Faceplate symbols, display conventions, and buttons
This section describes the symbols, display conventions, and buttons that are commonly used
on faceplates.
Meter faceplates
If your system uses Electronic Flow Measurement (EFM), some faceplates will represent
EFM meters, showing a description and the status of the meter. You can acknowledge alarms
on the EFM meter.
See the topics titled "Faceplate Indicator Zone symbols" and "EFM meter faceplates" for
more information.
Using faceplates
Honeywell 2017 69
