Honeywell Experion LX User Manual

Faceplate file
name
Faceplat
e type
Description
MOD
E?
OP
/
S
P?
Auto
selec
t?
Auto select
element
Behavior
the operator
changes the
faceplate's
mode to
MAN.
Faceplates where auto-selection is not available
Auto-selection is not suitable for the following faceplates. Therefore, these faceplates do not
support auto-selection.
Faceplate file
name
Faceplate type Description
sysdtlacc_fp.hda
SCADA Point
Faceplate
Accumulator Point
sysdtlash_fp.hda
Enterprise Model
Faceplate
Asset Point
sysdtlclh_fp.hda
Enterprise Model
Faceplate
Alarm Group Point
sysdtlaga38detaila_
fp.hda
Process Point
Faceplate
American Gas Association (AGA) - AGA 3 Orifice
Meter, AGA 8 Detail Setup Data
sysdtlaga38grossa_
fp.hda
Process Point
Faceplate
American Gas Association (AGA) -AGA 3 Orific
Meter, AGA 8 Gross Setup Data
sysdtlaga78detaila_
fp.hda
Process Point
Faceplate
American Gas Association (AGA) - AGA 7 Turbine
Meter, AGA 8 Detail Setup Data
sysdtlaga78grossa_
fp.hda
Process Point
Faceplate
American Gas Association (AGA) - AGA 7 Turbine
Meter, AGA 8 Gross Setup Data
sysdtlaga98detaila_
fp.hda
Process Point
Faceplate
American Gas Association (AGA) - AGA 9 Ultrasonic
Meter, AGA 8 Detail Setup Data
sysdtlaga98grossa_
fp.hda
Process Point
Faceplate
American Gas Association (AGA) - AGA 9 Ultrasonic
Meter, AGA 8 Gross Setup Data
sysdtlannpanela_
fp.hda
Process Point
Faceplate
Alarm Panel Block
sysdtldigacqa_ Process Point
Digital Acquisition Block
Reference topics
Honeywell 2017 328
