What is the System Status display?
The System Status display is similar to the Alarm Summary, however the System Status
display shows system alarms for system and network components only.
You can use the System Status display to:
n
Check the status of components to verify that they have been configured correctly and
are operating correctly.
n
Respond to system alarms such as:
l
Communications failures
l
Station failures
l
Operator logon failures
l
Printer failures.
n
Monitor the status of the system to prevent problems occurring.
n
Diagnose problems in the system.
n
Review firmware versions for C300 controllers.
Calling up the System Status display
There are several ways to call up the System Status display:
n
Using the Station menu
n
Using the Station Status Bar, usually in response to a system alarm
To call up the System Status display using the Station menu
1. In Station choose ViewSystem Status Display.
To call up the System Status display using the Status bar
1. In Station, click the System box in the Status bar.
If there is a system alarm, the System box is flashing.
Components of the System Status display
There are several parts that make up the System Status display. The following figure shows
What is the System Status display?
Honeywell 2017 290
