Page #200 background image
Displaying point history
To see changes to a point's PV (process value) over time
1. Display the point's Detail display.
2. Click the History tab.
This tab contains a set of History buttons.
3. Select the appropriate graphing options. For example, to see changes at minute inter-
vals, select 1minute from the Interval list.
Accumulator point
An accumulator point is a standard point type with a fixed data structure that represents total
values. For example, an accumulator point can represent the volume of water that has flowed
into a tank or through a turbine.
If you have the appropriate security level, you can change the point's properties.
Caution:
Changing point properties in Station will not update the Quick Builder project.
Honeywell recommends that, after updating the point in Station, you upload it into
Quick Builder to synchronize the project.
Faceplate
Shows critical information about the point, and provides a convenient means of controlling
the point. Many faceplates look like the front panels of the field devices they represent.
See the topic titled "Typical faceplates for the major point types" for more information.
General tab
Item Description
Range
Units The name of the engineering units. For example, Gallons, Liters, °F, and °C.
100% The value that represents 100% of the engineering units. The default is 100.00
Raw value The value of the last scan of the PV.
Displaying detailed process information
Honeywell 2017 200
