Honeywell Experion LX User Manual

Abnormal
value
Color Condition
??????? Red
Display field configured incorrectly (for example, not enough
characters for data value).
??????? or
(last known
value)
Gray Scanning of point currently disabled.
??????? or
(last known
value)
Inverse Controller or channel currently disabled.
Alarm state icons
The following table describes the icons used to indicate the “most important” alarm on a point
on custom displays, point detail displays, and elsewhere in Station. In determining which
alarm is the most important, the system takes into account factors such as the alarm priority,
alarm state, and whether or not the alarm has been acknowledged.
Attention:
The alarm colors described below are the default alarm colors. Your system may
use custom alarm colors.
If the icon looks like
this…
…and it
The alarm state
is…
…its
priority is
…and its acknowledge
status is
Flashes Active
Critical
priority
Not acknowledged
Flashes Active
Urgent
priority
Not acknowledged
Flashes Active
High
priority
Not acknowledged
Flashes Active Low priority Not acknowledged
Flashes Inactive
Critical
priority
Not acknowledged
Flashes Inactive
Urgent
priority
Not acknowledged
Alarm state icons and their meanings
Using displays
Honeywell 2017 57
