Calling up a Point Detail display
There are several ways of calling up a Point Detail display.
If your system uses DSA or point servers, information on some points you may need to
access is stored on remote computers. As a result, the first time you call up the point's details
you may need to type the full point ID. After this, using part of the point ID produces a
matching point.
To call up a detail display for a point associated with a display object
1. Click the display object to select it.
2.
Click the (Detail) toolbar button to call up the associated Point Detail display.
Alternatively, you can simply double-click the display object.
To call up a detail display for the point in the Alarm Line
1. Select the alarm associated with the point.
2.
Click the (Detail) toolbar button.
To call up a detail display for a point whose ID (or the first part of it) you know
1.
Type all or part of the point ID in the Command Zone, and then click the (Detail)
toolbar button.
2. If you typed only part of the ID, a list of matching points (and other items) appears.
Double-click the required point name.
To call up a detail display for a point whose full item name (or the first part of it)
you know
1.
Type all or part of the full item name in the Command Zone, and then click the
(Detail) toolbar button.
2. If you typed only part of the full item name, a list of matching points (and other items)
appears. Double-click the required point name.
Displaying detailed process information
Honeywell 2017 199
