Honeywell Experion LX User Manual

Activity Data dialog box on a custom display
Mouse over the New Value box to see a tool tip containing the acceptable minimum
and maximum values for each parameter.
Tip:
Note that entry fields are only available for parameters that can be changed;
some parameters are non-adjustable. By default, the dialog box opens with
the non-adjustable parameters hidden. If you want to see the non-adjustable
parameters, select the Show non-adjustable parameters check box at the
bottom of the dialog box.
3. Continue to provide new parameter values as required, including on other tabs.
4. Click one of the buttons provided:
a. Clicking Start will send the values to the controller and automatically start the batch
or procedure.
b. Clicking Apply will send the values to the controller and then you can manually
start the batch or procedure using the Activity commands.
Note that when you click Apply the set of parameter changes are written to the
controller in a single operation, rather than a single parameter being updated. This
Editing a batch or procedure
Honeywell 2017 261

Honeywell Experion LX Specifications

General

Brand	Honeywell
Model	Experion LX
Category	Control Systems
Language	English
