To call up the Press
Group Trend display for the selected objected. If there is no associated Group
Trend display, pressing the key invokes the Group Trend command and requires a
Group Trend number to be entered.
UNIT
TREND
Group display for the selected object. If there is no associated Group display,
pressing the key invokes the Group command and requires a Group number to be
entered.
GROUP
Trend for the selected object. If there is no associated Trend, pressing the key
invokes the Trend command and requires a Trend number to be entered.
TREND
Group history for the selected point with the default interval. If there is no
associated Group History, pressing the key invokes the Group History command
and requires a Group History number to be entered.
HOUR AVG
Calling up other displays
To call up Press
A display based on its name or number SCHEM
The next display upwards PAGE BACK
The next display downwards PAGE FWD
Navigate forward and backward between displays that you have
previously called up.
DISP FWD does not work if you are using multi-window Station.
PRIOR DISP or DISP
BACK
DISP FWD
The display associated with the selected object ASSOC DISP
Copy the current display to the first associated Station DISP SET
Print the current display PRINT DISP
Display-specific help (If display-specific help is not configured, calls
up Station Help.)
HELP
Changing focus
The term 'focus' used here means selecting a display object so that it will receive keyboard
input. For example, if you wanted to move the focus to the next box so that you could change
its value, you would use the Tab arrow keys.
To change focus to Press
Move the focus to any selectable object or editable box in the display TAB arrow keys
Reference topics
Honeywell 2017 312
