COMMISSIONING
Part No.: 4417340 Revision 1 Service Manual 103
954 SmartServo FlexLine
If the [Status Behavior] is set to <Not Used>, the respective relay will
not be activated if the scanned PV or SV health is Bad or Uncertain.
☛ Set the [Status Behavior] entity either to <BAD>, <BAD-
UNCERTAIN>, or <Not Used>.
NOTE:This behavior takes priority over the [Remote] or [Local]
monitoring. For example: If the [Status Behavior] is set to <BAD>, and
the scanned PV or SV health is Bad, the respective relay will be
activated regardless of the [Monitor Mode] entity settings. The [Remote]
or [Local] option PV or SV checks will then not affect the relay status.
7.3.6.4.4 Remote Control
In [Remote Control] mode, each individual relay can directly be
activated or deactivated, by sending an !Activate! respectively a
!Deactivate! command via the CAN bus.
The behavior of each individual relay is further controlled by the
[Remote Control] mode entity, which can be set to either <Restricted>
or <Not Restricted>.
 If the [Remote Control] mode entity is set to <Not
Restricted>, any source can be used to control the relay
with an !Activate! or a !Deactivate! command.
 If the [Remote Control] mode entity is set to <Restricted>,
the relay can only be controlled by the source that matches
the values set in the [Control Board ID], the [Control Board
Instance], and the [Control Function Instance].
☛ From the [Remote Control] mode menu, select either <Restricted> or
<Not Restricted>.
☛ If Not Restricted was selected, skip to 0.
☛ Select [Control Board ID], set proper value.
☛ Select [Control Board Instance], set proper value.
☛ Select [Control Function Instance], set proper value.
