COMMISSIONING
Part No.: 4417340 Revision 1 Service Manual 105
954 SmartServo FlexLine
7.3.6.5.3 Acknowledge
The !Acknowledge! command will cause the specified relay to be
physically deactivated, but the relay status will be set to
!Acknowledged!. This command is only available in [PV Monitor] mode;
see 7.3.6.4.1. This command can only be given when the concerned
relay has already been activated.
For example, this command is useful if the relay is connected to an
alarm system. The alarm can be silenced by the command, but it is still
possible to determine if an alarm has occurred. When the alarm
condition is then removed, the relay state will become deactivated, and
normal operation will resume.
7.3.6.6 LED Association
Depending on the value set in the [LED Association] entity, the 4
individual relays on the FII-DO board can be associated with one out of
2 LEDs, LE2 or LE3 (see Figure 7-7).
The associated LED will be ON when the relay state is <Activated>, and
the LED will be OFF when the relay state is <Deactivated>.
NOTE: The LEDs do not indicate the physical relay state (coil state or
contacts state), as this depends on the software settings and the
physical settings (jumper), see Relay Configuration 7.3.6.3.
☛
Set the value of the [LED Association] entity as desired (optional).
For an example, see table below.
LED Association LED Number Relay Number
1 + 2 LE2 1
LE3 2
3 + 4 LE2 3
LE3 4
7.3.6.7 Terminal Allocation
Terminal Number
Name
Function
14 Ry1_a Relay 1 Common
15 Ry1_b Relay 1 NO or NC*
16 Ry2_a Relay 2 Common
17 Ry2_b Relay 2 NO or NC*
18 Ry3_a Relay 3 Common
19 Ry3_b Relay 3 NO or NC*
20 Ry4_a Relay 4 Common
21 Ry4_b Relay 4 NO or NC*
*) See jumper settings, section 7.3.6.3.1
