SAFETY AND SECURITY
10 Service Manual Part No.: 4417340 Revision 1
954 SmartServo FlexLine
Security note 1
During commissioning the hardware full configuration write protect
jumper / switch for each FlexConn board should be placed so no
unintended or accidental configuration changes will be possible.
For security and unintended changes by people that are not allowed
making changes the "Protect all configuration jumper" must be placed
on all boards after device commissioning and a physical seal shall be
applied to the outsight of the device.
Put the "Protect all configuration entities" jumper of all relevant boards
so no external resource can modify anything of the configuration
(operational settings) of the 954 SmartServo FlexLine.
Security note 2
During (at a last step of the) commissioning the hardware W&M write
protect jumper / switch should be placed so no unintended or accidental
metrology configuration changes will be possible.
Security note 3
During commissioning the default Configuration Locks should be
changed at first use.
Board Default Configuration Lock
CAN-BPM (HCI-BPM) ENRAF2
CAN-HART (FCI-HRT) AAAAAA
CAN-TRL2 (HCI-TRL) ENRAF2
CAN-HART-SLAVE (HCI-HAO) ENRAF2
During (at a last step of the) commissioning the hardware
Configuration lock read protect jumper / switch should be placed
so the changed Configuration Locks could not be read out
anymore.
