Honeywell FlexLine SmartServo 954 - Commissioning of TII-LCD

COMMISSIONING
190 Service Manual Part No.: 4417340 Revision 1
954 SmartServo FlexLine
7.3.11.2 Commissioning of TII-LCD
For correct functioning of the TII-LCD module in the instrument, the
following entities can be set by using either Engauge or HART
SmartView.
Name Value Range Default Value Explanation
[Level type] <Innage>
<Ullage>
<Innage> It determines level
value to be displayed
on the LCD is Innage
Type or Ullage Type
[Display contrast] <0…63> 2 digits <35> Used to set the
contrast of the LCD
[Identification] 8 characters
E.g. Tank_123
<--------> Name of the tank or
instrument. This tank
name will be displayed
during start up and
showing of initial
screen is enabled. Only
special character
allowed is “_”
[Temperature Units] <Celsius>
<Fahrenheit>
<Celsius> Temperature value is
converted based on the
Temperature unit
selected and displayed
on the LCD
[Zero format] <format Numerical 0>
<format letter O>
<format
Numerical 0>
Zero of Process value
Level and Temperature
is displayed as per this
configuration
[Level units] <Metres>
<Feet>
<Inches>
<Fraction>
<Metres> Based on the level unit
selected process value
read from servo is
converted and
displayed on the LCD
[Decimal Separator] <Point>
<Comma>
<Point> Based on this
configuration decimal
separator is displayed
on the LCD screen
[Tenth millimeter
selection]
<enable>
<disable>
<enable> Determines whether
the tenth millimeter is
shown on the display in
the [PV screen] in case
a level entity is shown.
