COMMISSIONING
186 Service Manual Part No.: 4417340 Revision 1
954 SmartServo FlexLine
7.3.10.9 Troubleshooting
7.3.10.9.1 Gauge Scan Issue
1. Scan the SmartLink and check for the gauge address
mentioned in FCM-TRL/2 card.
2. If gauge address is not entered, enter the gauge address
and GPU address and read all the board parameters.
3. Reset FCM-TRL/2 card after reading all the parameters.
4. Make Commissioned option as “True” and press send.
5. Scan the gauge with proper Flex-conn and GPU address
provided in FCM-TRL/2 card (Recheck gauge and GPU of
gauge is same as entered in the FCM-TRL/2 card before
scanning the gauge).
7.3.10.9.2 TII-XR card Detection Issue
1. Scan the smartlink and provide respective gauge
address to the cards before you scan the cards.
2. Check if all cards are scanned which are present in the
gauge.
3. If TII-XR card is not detecting, check all other flex conn
boards for which the level parameter is linked are blinking
with healthy (Blue LED light comes on for every 5
seconds) status (Particularly HCI- HAO card).
4. If any of the Flex-conn board for which level parameter is
linked and is not healthy then switch off the gauge and
remove the unhealthy flex_conn board from the gauge.
5. Scan the gauge and observe TII-XR card is appeared in
scanning.
If the TII-XR card is appeared in scanning:
 Re-insert affected Flex_conn board into gauge (Gauge
should be switched off).
 Restart gauge and scan all boards once again.
If the TII-XR card is not appeared in scanning:
 Hardset the gauge and repeat all the steps from step
1.
