COMMISSIONING

226 Service Manual Part No.: 4417340 Revision 1

954 SmartServo FlexLine

Analog Output

Name Permitted Values Default Value Description

[Analog output

health]

(RO)

Status

GOOD

UNCERTAIN

BAD

Status Category

GOOD, ACTUAL VALUE

GOOD, STORED VALUE

UNCERTAIN, INSTRUMENT

BAD, HARDWARE FAILURE

BAD, OPERATIONAL

FAILURE

Status Code

See section 7.3.13.1 “Safety

Function Status” for

definitions.

Functional health of the

analog output.

Any status other than GOOD

will result in a safe state

activation for the analog

output.

[Analog output

mode]

< Disabled >

< Enabled >

< Disabled >

Disabled: the analog output

does not function and

remains at 0 mA current

value.

4-20 mA: The analog output

is in normal 4-20 mA mode.
