SYSTEM ARCHITECTURE
22 Service Manual Part No.: 4417340 Revision 1
954 SmartServo FlexLine
4.3 Entities
Information exchange between the various FlexConn modules takes
place by means of the entities.
An entity represents a unique information association in the FlexConn
architecture. This information may consist of measuring data, status
data, commissioning parameters, diagnostics data, or commands.
In addition to the information exchange between FlexConn modules,
entities are used for data presentation on the HART SmartView display,
and for the communication between the Engauge service tool and the
954 SmartServo FlexLine.
The entities are represented by a textual description, for example,
“Reset”, “Tank bottom”, “Health”, or “Baudrate”.
The entities structure is related to the following:
 General status information
 Generic FlexConn part
 Function-specific FlexConn part
Status Entities
The “Health” and “Commissioned” entities provide information about the
general FlexConn module status and the functions implemented on this
module.
4.3.1.1 Health En tity
The “Health” entity reflects the condition of the entire module, each
single module function, and the calculated or measured value of a
sensor function.
The “Health” entity structure is defined by following items:
1. status
2. status category
3. status code
The status field gives high-level information:
 good
 uncertain
 bad
