Honeywell FlexLine SmartServo 954 - Level Status Bytes; Density Status Byte

DENSITY OPTION
Part No.: 4417340 Revision 1 Service Manual 283
954 SmartServo FlexLine
Level status bytes
level status byte 0 level status byte 1
Bit Description Bit Description
0
general fail / default setting
0
trajectory exceeds level product level;
[Tank profile start distance] too small (TP
only)
1
no valid product level
1
density trajectory stops below stop level
(TP only)
2
level / trajectory exceeds motor
limit high level
2
no valid start or stop levels (IP only)
3
level / trajectory exceeds motor
limit low level
3
0
4
0
4
0
5
0
5
0
6
1
6
1
7
0
7
0
Density status byte
Bit Description
0 general fail / default setting
1 measurement not completed
2 0 = Tank Profile, 1 = Interface Profile
3 no measuring point or measuring point out of range
4 level / trajectory exceeds motor limit level
5 0
6
1
7
0
