TROUBLE SHOOTING
Part No.: 4417340 Revision 1 Service Manual 287
954 SmartServo FlexLine
Status code
(SmartView)
Description
(Engauge)
Remarks
6292 Wrong HART units device address
13
RIC warning
6293 Bad HART status device address
11
RIC warning
6294 Bad HART status device address
12
RIC warning
6295 Bad HART status device address
13
RIC warning
6296 Weight in vapor bad for density tilt
compensation
Errors
Codes in the range 6130-6271 are error codes. Errors will set the
status of the Primary value to BAD.
Status code
(SmartView)
Description
(Engauge)
Remarks
6130 Frequencies F0..F3 not
commissioned
Commissioning error (refer to section
7.4).
6131 Drum circumference not
commissioned
Commissioning error (refer to section
7.4).
6132 Motor limits high or low not
commissioned
Commissioning error (refer to section
7.4).
6133 Tank top level not commissioned Commissioning error (refer to section
7.4).
6134 Reference level not
commissioned
Commissioning error (refer to section
7.4).
6144 Frequency sensor failed to start
up
Hardware error of the frequency sensor.
6146 Find positions failed encoder
problem
Hardware error of the reference
encoder.
6148-6154 Sensor frequencies out of range Calibration of the frequency sensor
failed. Please check [Frequency 0] -
[Frequency 3].
6156 Frequency coefficients out of
range
Calibration of the frequency sensor
failed.
6158 Find positions failed offset to big The displacer level is unreliable. The
reference encoder needs to be
calibrated in maintenance mode (refer to
section 9.6)
6159 Find positions failed wire tension
error
The reference encoder could not be
checked because the wire tension is too
low or too high. Please check the wire
and displacer.
6160 Find positions failed no space The motor limits are too close to each
other. Find positions needs 10mm up or
downwards.
